VAG MChB imo data calculator

Ремонт та прошивка блокiв AUDI BCM2, клонування, чтение и перенос IMMO data, оновлення прошивки.

Ремонт та прошивка блокiв VAG ECU (блоки керування двигателем), клонування, перенос данних iммобилайзера, синхронизация, вiдновлення пiсля невдалоï прошивки, immo-off

Ремонт та прошивка блокiв VAG TCU (блок керування DSG, мультитроник)

Ремонт та прошивка блокiв VAG CCM (блок комфорта VAG)
Ремонт та прошивка блокiв AUDI ELV (блок керування защелки руля)

Ремонт та прошивка блокiв VW EZS (блок керування защелки руля)

Клонування плат керування ECU, TCU, ELV, EZS, BCM2 пiсле замiни, перенос всiх данных VIN, immo (eeprom ,flash)

ALL ECU VAG MEDC17(ME17/MED17/EDC17) clone, adaptation, immo-off. BCM2 clone, adaptation

MEDC17(ME17/MED17/EDC17) - Editor, import from (CCM / ECU/ SECURITY BLOCK)
SIEMENS PCR2.1 - Editor, import from (CCM / ECU/ SECURITY BLOCK)
SIEMENS PPD1.X - Editor, import from (CCM / ECU/ SECURITY BLOCK)

MED9 No Crypted - Editor, import from (CCM / ECU/ SECURITY BLOCK)
EDC16 - Editor, import from (CCM / ECU/ SECURITY BLOCK)
MM 9GV - Editor, import from (ECU/ SECURITY BLOCK)

MM 7GV - Editor, import from (ECU/ SECURITY BLOCK)
CCM PASSAT - Editor, export to (ECU/EMULATOR)
BCM2 AUDI A4/A5/Q5 - Editor, export to (direction to ECU/ELV/TCU/EMULATOR)
ELV AUDI WFS5 - Editor, import from (direction from BCM2)
ELV/EZS AUDI A6/Q7 - Editor, export to (direction to ECU)

EZS VW CRAFTER - Editor, export to (direction to ECU)

TCU MANAGER - automatic gearboxes VAG DQ200 MQB, DQ250 MQB, VL300, VL381, DL382, DL501, DQ200 MQB Gen2, DQ500, DQ381
For proper work module just need non encrypted full readout from TCU flash + eeprom, allowed is copy immo data beetwen TCU (EXEPT DL382) and change power class, viewer, editor

SIMOS18 /SIMOS12 /SIMOS10
For proper work module just need non encrypted full readout from ECU flash + eeprom , and also the ECU cannot use SHE (Secure Extension Hardware), allowed is copy immo data beetwen ECU and change power class, import immodata from BCM2 and other immo block

MED9.1.X CRYPTO
MEDC17 BOSCH POWER CLASS / MARKEN CLASS
SIMOS8.XX (SIMOS8.1, SIMOS8.2, SIMOS8.3, SIMOS8.4, SIMOS8.5, SIMOS8.6) -
MQB IMMO data manager
Module generate TCU/ECU/ELV synchronization data from SYNC_KEY 32 bytes and IMMO_BLOCK 189 bytes files readed by VVDI, You must have one working key for get this files
BCM2 A6/A7/A8/Touareg IMMO data manager
Generate TCU/ECU/ELV synchronization data from BCM2 MCU NEC files and SYNC_KEY 32 bytes or KEY 512 bytes file readed by VVDI
ELV MQB IMMO data manager, supports ELV with NEC v850 MCU Module allow edit, export /import immobilizer data in steering lock (ELV/ESL) MQB.
